2-Pin Screw Terminal Block 5.08mm Pitch (20 pcs)

2-Pin 5.08mm Pitch PCB Screw Terminal Blocks (Pack of 20)

Industrial-grade 2-position wire-to-board screw terminal blocks with standard 5.08mm (0.2") pin spacing. Molded from flame-retardant polyamide with interlocking dovetail slots on the sides, allowing multiple 2-pin blocks to be connected into 4, 6, or 8-pin terminals.

Specifications

• Terminal Pitch: 5.08 mm (0.2 inch) standard breadboard/PCB spacing
• Rated Voltage / Current: 300V AC / 16 Amperes
• Applicable Wire Gauge: 24 to 12 AWG (solid or stranded wire)
• Screw Type: M2.5 zinc-plated steel screws with cage clamp
• Housing Material: UL94V-0 flame-retardant nylon (blue)
• Interlocking modular design: Slide-connect multiple units together
