KY-040 Rotary Encoder Module

KY-040 Incremental Rotary Encoder Module with Pushbutton

The KY-040 is a continuous 360-degree rotary encoder providing 20 steps per full rotation with distinct tactile detents. By monitoring the phase relationship between its two quadrature outputs (CLK and DT), microcontrollers detect both rotational direction and speed.

Specifications

• Pulses Per Revolution: 20 pulses per 360° revolution
• Rotation: Continuous unbounded rotation in both directions
• Pushbutton: Integrated momentary tactile switch activated by pressing shaft
• Operating Voltage: 5.0V DC (onboard 10kΩ pull-up resistors included)
• Output Type: 2-bit quadrature Gray code (CLK and DT)
• Applications: Digital volume knobs, menu navigation, 3D printer interfaces
