L3G4200D 3-Axis Gyroscope Module

L3G4200D 3-Axis Digital Angular Rate Gyroscope

The STMicroelectronics L3G4200D is an ultra-low power 3-axis angular rate sensor delivering exceptional zero-rate bias stability across temperature fluctuations. Ideal for drone stabilization, robot dead reckoning, and camera optical image stabilization.

Specifications

• Selectable Angular Scales: ±250, ±500, and ±2000 degrees per second (dps)
• Digital Output: 16-bit rate data over I2C and SPI (3-wire and 4-wire)
• Operating Voltage: 2.4V to 3.6V (breakout includes 3.3V LDO and level shifter)
• Bandwidth: User-selectable low-pass and high-pass internal digital filters
• Current Draw: 6.1 mA in normal active mode, 5 μA in power-down mode
• Integrated temperature sensor with 8-bit digital output
